Default Installing audio amp and speakers

I'm installing an audio amp and handlebar speakers on my 01 V92C Deluxe.

My problem is that I can't seem to figure out where to patch in the power for the amp. I've seen folks tie directly into the fuse box before, but it doesn't seem to matter which fuze I try, I get constant power - instead of only power when the bike is on. It appears that the fuze box is hot all the time.

Can anyone suggest to me from WHERE I should be drawing power?

Obviously, I could easily build a switch to shut if off....but I'd rather just have it patched in somewhere so that it only comes on after the ignition has been turned on.

Thanks for your advice!
skullsessions is offline
Sponsored Links
Advertisement

post #2 of 5 (permalink) Old 08-05-2011, 06:10 PM
Senior Member

Tenac's Avatar

Join Date: Sep 2010
Location: AZ
Posts: 257
Default

I recently installed the Sound of Chrome speakers to my handlebar and ran into this problem from the fuse box. So I hooked up directly to the battery. My system comes with an off/on switch so no worries. Just to be sure I put my meter on to measure my draw and there was nothing so it won't drain the batter. Also its been left for 7 days not running and everything is still fine. I guess I'm curious where anyone might pull that power from??? Maybe the key switch???

2008 Hammer
LED
2 into 1 No baffle
Lloydz intake
Power Commander 3
CHROME
Speakers
Tenac is offline
post #3 of 5 (permalink) Old 08-05-2011, 07:45 PM
Member

Join Date: Mar 2011
Posts: 92
Default

Pictures please! also this project is on my wish list what system did you install?

Thanks

Bill
mrbill65 is offline
Sponsored Links
Advertisement

post #4 of 5 (permalink) Old 08-05-2011, 08:38 PM
Senior Member

Tenac's Avatar

Join Date: Sep 2010
Location: AZ
Posts: 257
Default

You can see the pics in my profile. kuryakyn sound of chrome. They are very nice but let me warn you. Make sure you OUTPUT of the MP3 player or phone is enough. I'm still searching for the right one. My phone output more then my mp3. My buddies ZUNE is AWESOME but cost a shit ton. So im looking for better options.

2008 Hammer
LED
2 into 1 No baffle
Lloydz intake
Power Commander 3
CHROME
Speakers
Tenac is offline
post #5 of 5 (permalink) Old 08-05-2011, 11:39 PM Thread Starter
Senior Member

skullsessions's Avatar

Join Date: Jul 2011
Location: Houston/Katy
Posts: 244
Garage
Default

I actually solved my power problem this evening.

Under the seat, I was able to locate the wiring going back to the tail section. I opened a disconnect there and used a multimeter to find a wire that went hot when the ignition was activated. Spliced into that wire for the amp. Works like a charm now...and you literally can only see the speakers and an 1/8" connector at the handlebars. Very clean.

Tomorrow, the Ram mount arrives to mount my iPhone...which I'll be using as an MP3 player. I also downloaded TomTom for the iPhone....which, having used in my car over the last couple of days, seems to be working quite well. The sweet thing about having everything on the same unit is that TomTom will fade music for the voice directions, then bring it back to volume afterward. Pretty cool.

Now, if we could just find a water tight iPhone case that doesn't have reviews where users say it overheats, we'd be all set.

Here's a shot of the speakers. Not really much to see...which is a good thing. Wires run up under the gas tank to behind the right-side panel cover, where the fuze box is.

Amp is mounted to the frame under there. Even though it's a waterproof amp, I didn't see any reason to expose it to rain purposely.



Oh yeah...got this system from motorcycletunes.com

This is the Polk audio system with the 600w water proof amp. Came with speaker clamps and all the hardware necessary to install. Plenty of wire to get things where you want them. In fact, I cut off about 4 feet of excess speaker wire. Note...it didn't come with any zip ties or anything to secure the wires to the frame.

I actually called these guys before I placed an order, since I hadn't heard of them. Very informative. Shipped that day. Arrived in two days via UPS. Packed pretty well. Instructions were excellent. The hardest part was figuring out where to put the amp, and where to find the power.
